关于自动焊接设备的基本构成

来源:http://www.tayfsk.com/  发布时间:2022-11-24 浏览次数:

在机械行业中,一般都会用到自动焊接设备,对于刚接触这一行业的人来说,对设备还尚不熟悉,今天山东自动焊接设备厂家就为大家简单介绍下,设备的基本构成和特点等内容,希望刚入行的新手能用到。
In the mechanical industry, automatic welding equipment is generally used. For those who are new to this industry, they are still unfamiliar with the equipment. Today, Shandong automatic welding equipment manufacturer will give you a brief introduction to the basic composition and characteristics of the equipment. I hope that novices can use it.
1、焊接电源。其输出功率和焊接特性应与拟用的焊接工艺方法相匹配,并装有与主控制器相连接的接口。
1. Welding power source. Its output power and welding characteristics shall match the proposed welding process method and be equipped with an interface connected to the main controller.
2、送丝机及其控制与调速系统。对于送丝速度控制精度要求较高的送丝机,其控制电路应加测速反馈。
2. Wire feeder and its control and speed regulation system. For wire feeder with high control accuracy of wire feeding speed, speed measurement feedback shall be added to its control circuit.
3、主控制部分,亦称系统控制器。主要用于各组成部分的联动控制,程序的控制,主要参数的设定,调整和显示。必要时可扩展故障诊断和人机对话等控制功能。
3. The main control part is also called the system controller. It is mainly used for linkage control of various components, program control, setting, adjustment and display of main parameters. If necessary, control functions such as fault diagnosis and man-machine conversation can be extended.
4、焊件移动或变位机构。如焊接滚轮架,头尾架翻转机,回转平台和变位机等,精细型的移动变位机构应配伺服电动机驱动。
4. Weldment movement or displacement mechanism. For example, welding roller frame, head and tail frame turnover machine, rotary platform and positioner, etc., fine mobile positioner shall be driven by servo motor.
5、焊头导向或跟踪机构。弧压自动控制器,焊枪横摆器和监控系统。
5. Welding head guide or tracking mechanism. Automatic arc voltage controller, welding torch sway device and monitoring system.
6、焊接机器人,又称机械手臂,是自动化焊接设备的重要组成部分,其主要工作包括:焊接、切割、热喷涂、搬运等。
6. Welding robot, also known as robot arm, is an important part of automatic welding equipment. Its main work includes: welding, cutting, thermal spraying, handling, etc.
7、计算机软件。设备中常用的计算机软件有编程软件,功能软件,工艺方法软件和专家系统等。
7. Computer software. The computer software commonly used in the equipment includes programming software, functional software, process method software and expert system.
8、辅助装置,如送丝系统,循环水冷系统、焊剂回收输送装置、焊丝支架、电缆软管及拖链机构结构设计电气控制设计三大部分。
8. Auxiliary devices, such as wire feeding system, circulating water cooling system, flux recycling and conveying device, welding wire support, cable hose and drag chain mechanism, are mainly designed for electrical control.
操作人员在使用自动焊接设备的时候,要提前了解设备的相关特点、组成等功能,以免在后期使用中出现问题,大家如果有意向选购的话,欢迎http://www.tayfsk.com前来咨询。
When using automatic welding equipment, operators should know the relevant features, composition and other functions of the equipment in advance to avoid problems in later use. If you are interested in purchasing, welcome http://www.tayfsk.com Come to consult.
