数控焊接操作时需要注意什么?

来源:http://www.tayfsk.com/  发布时间:2022-04-07 浏览次数:0

焊接操作机作为现代工业机械发展重要的一部分,使用的人也越来越多了,它本身具有很多优点,无需焊丝、操作简单、生产率高、热影响区小等等,在使用过程中也有很多需要注意的事项,今天小编就为大家介绍一下焊接操作机使用时候的注意事项~

As an important part of the development of modern industrial machinery, more and more people use the welding machine. It has many advantages, such as no welding wire, simple operation, high productivity, small heat affected zone, etc. there are also many matters needing attention in the use process. Today, the editor in chief of tian will introduce the matters needing attention in the use of the welding machine~
1、焊接完成后,应切断闸断电,将地线和把线分开,并在离开现场前确保熔渣的火星是熄灭状态。
1. After welding, the gate shall be cut off and the power shall be cut off, the ground wire shall be separated from the connecting wire, and the spark of molten slag shall be extinguished before leaving the site.
2、严禁用金属管、金属脚、轨道、结构钢筋等金属物体代替地线。
2. It is strictly prohibited to replace the ground wire with metal objects such as metal pipe, metal foot, track and structural reinforcement.
3、装卸乙炔气(瓶或石油气瓶应注意轻拿轻放,不得抛、碰、滑、滚等剧烈震动。
3. When loading and unloading acetylene gas cylinders or petroleum cylinders, pay attention to handle them with care, and do not throw, touch, slide, roll and other violent vibrations.
4、乙炔瓶表面温度不得超过40度。
4. The surface temperature of acetylene cylinder shall not exceed 40 ℃.
5、在同一地点使用氧气瓶和电焊时,应注意瓶底绝缘,以防止瓶体带电。
5. When using oxygen cylinders and electric welding in the same place, pay attention to the insulation at the bottom of the cylinder to prevent the cylinder from being charged.
6、户外使用电焊机时,应设置防水、防潮机械棚,并配备消防设备。
6. When the electric welding machine is used outdoors, a waterproof and moisture-proof mechanical shed shall be set and equipped with fire-fighting equipment.
7、电焊钳过热后不可以浸在水中冷却后使用。
7. Electric welding tongs cannot be used after being immersed in water and cooled after overheating.
8、焊机一次测的电源线长度不超过5米。
8. The length of the power line measured by the welder at one time shall not exceed 5m.
9、焊机二次测把线及地线长度不超过30米。
9. The length of secondary measuring line and ground wire of welding machine shall not exceed 30m.
10、焊机把线电缆应采用橡胶套多股细铜线软电缆。
10. The handle cable of the welding machine shall adopt the flexible cable of multi strand thin copper wire with rubber sleeve.
11、交流电焊机空载电压不得超过80伏。
11. The no-load voltage of AC welding machine shall not exceed 80V.
12、氧气瓶和乙炔气瓶之间的距离不得小于5米。
12. The distance between oxygen cylinder and acetylene cylinder shall not be less than 5m.
13、进行二氧化碳气体保护焊时,作业前二氧化碳气体预热15分钟。
13. When carbon dioxide gas shielded welding is carried out, the carbon dioxide gas shall be preheated for 15 minutes before operation.
这些注意事项只有按照正确的操作方法,正确的使用流程,才能更好的使用。
These precautions can be better used only according to the correct operation method and correct use process.
以上就是为大家介绍的有关山东数控焊接设备的详细介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务http://www.tayfsk.com
The above is the detailed introduction of Shandong CNC welding equipment. I hope it will help you If you have any questions, please contact us We will provide you with professional service http://www.tayfsk.com
